Square Alumina Rods - Alumina Ceramic Rods

Brand: Yunxing
Product origin: China
Delivery time: Depending on product size and quantity
Supply capacity: 5,000-10,000/month(Looking for distributors)

1. Aluminum oxide (Al2O3) is known for its excellent mechanical strength and hardness. Square alumina rods benefit from these characteristics, making them wear-resistant, wear-resistant, and high impact resistant. 2. Square alumina rods are highly stable at high temperatures, with a melting point exceeding 1700 ° C, making them suitable for high-temperature applications. 3. Alumina ceramics are excellent electrical insulators, making square alumina rods an ideal choice for applications that require high voltage or extreme resistance. 4. The square alumina rods is resistant to chemical corrosion, ensuring durability in environments exposed to harsh chemicals, acids, or alkalis. 5. Square alumina rods have high dimensional stability, making them suitable for precision applications. Over time, they also exhibit minimal deformation. 6. The square alumina rods has biocompatibility, which means it is non-toxic and suitable for medical and laboratory environments.

Email Annex

Square Alumina Rods - Alumina Ceramic Rods

Alumina Rods

Advantages of Square Alumina Rods

1. Aluminum oxide (Al2O3) is known for its excellent mechanical strength and hardness. Square alumina rods benefit from these characteristics, making them wear-resistant, wear-resistant, and high impact resistant.

2. Square alumina rods are highly stable at high temperatures, with a melting point exceeding 1700 ° C, making them suitable for high-temperature applications.

3. Alumina ceramics are excellent electrical insulators, making square alumina rods an ideal choice for applications that require high voltage or extreme resistance.

4. The square alumina rods is resistant to chemical corrosion, ensuring durability in environments exposed to harsh chemicals, acids, or alkalis.

5. Square alumina rods have high dimensional stability, making them suitable for precision applications. Over time, they also exhibit minimal deformation.

6. The square alumina rods has biocompatibility, which means it is non-toxic and suitable for medical and laboratory environments.

Applications of Square Alumina Rods

1. Square alumina rods are commonly used in furnace components such as brackets and heating elements because they can withstand high temperatures without deformation.

2. Square alumina rods are widely used in electrical and electronic applications, including transformers, distribution systems, and semiconductor manufacturing.

3. Square alumina rods are used as support structures to provide strength and heat resistance.

4. Square alumina rods have become an ideal choice for medical devices, laboratory equipment, and chemical processing, where purity and durability are crucial.

5. Square alumina rods can be used for various mechanical engineering applications that require precision, wear resistance, and strength. These include mechanical parts, cutting tools, and other high-performance engineering components.

6. Square alumina rods play a crucial role in insulation and protection in high-pressure environments, ensuring the safety and reliability of systems that can withstand high-power loads.

How to clean alumina ceramic stick

1. First, place the alumina ceramic stick in a solution of warm water and mild detergent.

2. Use a soft cloth or brush to scrub the rod gently, taking care not to damage the ceramic.

3. Rinse the rod off with clean, warm water and make sure all detergent residue is removed.

4. Dry the alumina ceramic stick with a clean, soft cloth, and inspect it for any remaining dirt or debris.

5. If necessary, repeat the cleaning process until the rod is free of any residu.

Size,Performance index

Alumina round rods Specification Table
Number	Diameter		LENGTH MM	Number	Diameter		LENGTH MM
Number	INCH	MM	LENGTH MM	Number	INCH	MM	LENGTH MM
1	0.031	0.79	≤1250	25	0.630	16	≤1500
2	0.039	1		26	0.669	17
3	0.059	1.5		27	0.688	17.5
4	0.062	1.58		28	0.748	19
5	0.079	2	≤1500	29	0.750	19.05
6	0.100	2.5	≤1500	30	0.787	20
7	0.118	3	≤1750	31	0.827	21
8	0.125	3.18		32	0.866	22
9	0.157	4		33	0.906	23
10	0.187	4.75		34	0.945	24
11	0.197	5		35	0.984	25
12	0.236	6		36	1.000	25.4
13	0.250	6.35		37	1.063	27	≤1250
14	0.276	7		38	1.126	28.6	≤1250
15	0.312	7.92		39	1.181	30	≤800
16	0.315	8		40	1.250	31.75
17	0.333	8.47		41	1.378	35
18	0.375	9.53		42	1.500	38.1
19	0.394	10		43	1.575	40
20	0.433	11		44	1.654	42
21	0.472	12		45	1.750	44.45	≤500
22	0.500	12.7		46	1.875	47.6	≤500
23	0.551	14	≤1500	47	1.969	50	≤300
24	0.591	15	≤1500	48	2.000	50.8	≤300

Alumina ceramic performance index (Notice of Correct in Leakeage Rate）

NO.	Property	Unit	Alumina
1	Al2O3	%	>99.3
2	SiO2	%	—
3	Density	g/cm3	3.88
4	Water absorption	%	0.01
5	Compressive strength	MPa	2300
6	20℃ leakage rates	Torr・L/sec	>10-11=1.33322×10-12Pa・m3/sec
7	Twisting in high temperature	mm	0.2 allowed in 1600℃
8	Bonding in high temperature		not bonded in 1600℃
9	20—1000℃ coefficient of thermal expansion	mm.10-6／℃.m	8.2
10	Thermal conductivity	W/m.k	25
11	Electric insulation strength	KV/mm	20
12	20℃direct current insulation resistance	Ohm/cm	1014
13	High-temperature insulation resistance	1000℃ MΩ	≥0.08
13	High-temperature insulation resistance	1300℃ MΩ	≥0.02
14	Thermal shock resistance		4 times not cracked in 1550℃
15	Maximum working temperature	℃	1800
16	Hardness	Mohs	9
17	Flexural strength	Mpa	350

Our factory

Jinzhou Yunxing Industrial Ceramics Co., Ltd. was established in 2000, mainly producing various types of tubular ceramic products and various industrial parts with alumina content above 99.3%. The factory covers an area of 4000 square meters.

The company's main products are: alumina ceramic tubes, alumina ceramic crucibles, alumina ceramic rods, alumina ceramic boats, alumina ceramic plates, alumina ceramic parts, etc.

The company currently has 3 1800 ° C high-temperature furnaces and 2 1400 ° C low-temperature kilns independently designed and manufactured. The molding process is mainly based on grouting molding, and has other molding process equipment such as extrusion and hot die casting.

The company has 105 employees, including one senior ceramic engineer, three engineers, six overseas sales staff, and four professional after-sales staff.

FAQ

Q1. What information should we supply to get a quote?

A1. Please offer the specification of ceramic rod, such as shape, dimension, quantity, application etc.

Q2: What are the benefits of using alumina rods for industrial?

A2. The alumina ceramic sticks is strong, rigid, and capable to withstand senior high temperatures and pressures.They are lightweight, easy to clean, and corrosion resistant.

Q3: What types of industria applications can alumina ceramic sticks be used for?

A3. Qualification Alumina ceramic sticks an ideal choice for a variety of industrial and commercial applications.They can be used for drilling, grinding, and cutting.
